API 5L ,API 5CT certificated

 API 5CT OIL TUBING

Standard:

API SPEC 5CT、API SPEC 5B、ISO 11960:2004

Grade:

H40、J55、N80-1、N80Q、L80、C90、T95、P110

Size:

OD:48.26~114.3mm, Thk:3.68~16mm(1.9"~4 1/2")

thread type:

EUE,NUE

Length:

R1(6.10m~7.32m)、R2(8.53m~9.75m)

Usage:

A pipe for producing fluid or injecting liquid into a well,When the drilling is completed, crude oil and natural gas are transported from the reservoir to the surface.

Speficication:

1.9"TUBING 1.9" 2.75lb/ft 1.9" 2.75PPF 48.26*3.68 J55 N80  NUE  R-2
1.9"TUBING 1.9" 3.65lb/ft 1.9" 3.65PPF 48.26*5.08 J55 N80  NUE  R-2
2-3/8"TUBING 2-3/8" 4.60lb/ft 2-3/8" 4.6PPF 60.3*4.83 J55 N80 L80 P110 NUE  R-2
2-3/8"TUBING 2-3/8" 4.70lb/ft 2-3/8" 4.7PPF 60.3*4.83 J55 N80 L80 P110 EUE  R-2
2-7/8"TUBING 2-7/8" 6.40lb/ft 2-7/8"  6.4PPF 73.02*5.51 J55 N80 L80 P110 NUE  R-2
2-7/8"TUBING 2-7/8" 6.50lb/ft 2-7/8" 6.5PPF 73.02*5.51 J55 N80 L80 P110  EUE  R-2
3-1/2"TUBING 3-1/2" 9.20lb/ft 3-1/2" 9.2PPF 88.9*6.45 J55 N80 L80 P110 NUE  R-2
3-1/2"TUBING 3-1/2" 9.30lb/ft 3-1/2" 9.3PPF 88.9*6.45 J55 N80 L80 P110  EUE  R-2
4"TUBING 4" 10.70lb/ft 10.7PPF 4" 101.6*6.65 J55 N80 L80 P110 NUE  R-2
4"TUBING 4" 11.00lb/ft 11PPF 4" 101.6*6.65 J55 N80 L80 P110  EUE R-2
4-1/2"TUBING 4-1/2" 12.60lb/ft 4-1/2" 12.6PPF 114.3*6.88 J55 N80 L80 P110  NUE R-2
4-1/2"TUBING 4-1/2" 12.750lb/ft 4-1/2" 12.75PPF 114.3*6.88 J55 N80 L80 P110  EUE R-2
